How to set gain/offset for 4AD module?

Below is gain/offset caculate formula:

Note: the unit of Analog input is μA

For value of "constant" please check the table:

For example, when set channel as 4mA~20mA to 0~1000, the default offset, gain, constant is 4000, 20000, 1000.

If user want to change it as 4mA~20mA to 0~200, the gain/offset calculation can be done by the following two formulas:

1. 0=(4000-offset)*1000/(gain-offset)

2. 200=(20000-offset)*1000/(gain-offset)

So the offset and gain should be 4000 and 84000
